FEATURES & APPLICATIONS
With TELEHOOK products, mounting large LCD and plasma TVs and displays is easy. The TELEHOOK range offers comprehensive solutions for small (from 12”) and large (up to 63”) displays in the home and commercial environments. The wide range includes wall and ceiling mounts as well as universal solutions for mounting projectors, giving you the flexibility to choose the best way to mount your display. TELEHOOK mounts are easy to install and guarantee that your display will be securely mounted.
Key Features:
- Quick release mechanism for fast and easy display attachment/removal
- Supports displays up to 20kgs (44lbs)
- Supports displays with VESA mounting hole configurations:
- 50mm x 50mm (2" x 2")
- 75mm x 75mm (3" x 3")
- 100mm x 100mm (4"x 4")
- Screen tilt adjustment from –10˚ to +20 ˚
- Horizontal adjustment of –/+5 ˚ for leveling screen
- Two pivot points of 190 ˚ at wall and behind screen
- Minimum distance from wall 75mm (3")
- Maximum reach from wall 250mm (10")
- Internal cable management
- Masonry, timber stud & dry wall mounting hardware included
